Full Automatic Round Rotary Plastic Bottle Unscrambler Glass Bottle Sorting Turntable Feeding MachineFull Automatic Round Rotary Plastic Bottle Unscrambler Glass Bottle Sorting Turntable Feeding MachineFull Automatic Round Rotary Plastic Bottle Unscrambler Glass Bottle Sorting Turntable Feeding Machine

Full Automatic Round Rotary Plastic Bottle Unscrambler Glass Bottle Sorting Turntable Feeding Machine

  • Product Item:Model YTK-S800
  • Dimension(L*W*H): 65*100*100cm
  • Weight: 65 KG
  • Power: 120W
  • Package size 1050*1000*1130mm
  • bottle unscrambler
    Inquiry Send Email

    Description

    Product Description

    This series of equipment is mainly used for the storage, turning and automatic bottle feeding of the front process of the filling machine.Widely used in food, medicine, daily chemical, hardware, plastic, cosmetics and other industries

    Product Paramenters
    Model
    YTK-S800
    Conveying speed
    0-20 revolutions per minute(adjustable)
    Voltage
    200V 50Hz (110V can be customized)
    Power supply
    200W
    Turntable diameter
    800 mm Available
    Dimensions
    1000*1000*900mm
    Package size
    1050*1000*1130mm
    Net weight/Gross weight
    129kg/131.5kg
    Application
    This series of equipment is mainly used for the storage, turning and automatic bottle feeding of the front process of the filling machine.Widely used in food, medicine, daily chemical, hardware, plastic, cosmetics and other industries.
    Detailed Images
    The machine with the S shape component is designed for getting bottles in order and can be transported neatly.Normally it will be coonected before the filling machine,it's the first step in aoutomated production.
    This machine without S shape component is designed for receiving finished products,normally it will be connected after labeling machine,it is the last step in automated production.
    Designed for diameter 30-100mm Bottles,it can group 40-60 bottles/min.
    The working speed is adjustable according to production need,help to control the machine better.
    The inlet and outlet can be changed according to bottle diameter by adjusting the screw,this is good for different sizes of
    bottles.
